The safety valve is:
specific for the Refrigeration sector, suitable for use with:
refrigerants (Freon)
CO2/R744 up to 300 Bar
ammonia/NH3
automatically activated, with free or conveyed discharge
produced in brass UNI EN 12164 CW614N or stainless steel UNI EN 10088 1.4404 / SA479 S31603; the spring is always supplied in steel UNI EN 10270-1
The safety valve is certified CE IV - ASME XIII - EAC - CRN – SELO – UKCA – ATEX.
External tests can be performed by the most prestigious authorities such as: TÜV, RINA, ABS, Lloyd Register, DVN
Ammonia/NH3 safety valves, stainless steel UNI EN 10088 1.4404 / SA479 S31603
A complete series with:
- orifices from 7 to 25 mm and connections from 1/4’’ to 1’’1/2 GAS ISO228 or NPT
- set pressures from 0.3 to 60 bar (PN60)
seals:
- PTFE (-196 ° C + 250 ° C)
- metallic (-196 ° C + 450 ° C)
